- Place of Origin: china
- Brand Name: liuxing
- Model Number: 9ZP-30
【main feature】
Compact and reasonable design, safe and reliable.
The frame adopts a steel frame design and is equipped with a walking wheel and is easy to move.
Advanced grass feeding mechanism, unique feeding roller device, automatic feeding, no chain-wrap on the conveyor chain, smooth grass feeding and high productivity.
The universal roller joint is used for the drive shaft of the roller. It is flexible in operation and easy to disassemble and install.
The rake blade is made of high-quality steel and processed by special technology. It is super wear-resistant and uses high-strength bolts. It is safe and reliable to use.
The chassis is made of thick steel plate welded, the whole mold is formed, the anti-counterfeiting mark is suppressed, and the product is beautiful and durable.
The grass rake has a superior price/performance ratio, and the same productivity rake has the lowest price.
Wide applicability, can process different crop straws and materials.
The machine is a large-scale straw processing machine with the largest domestic model, the most advanced design, and specific intellectual property rights.
【Scope of application】
It is suitable for processing boring cutting processing of high-hardness, coarse fiber, such as various crop stalks, cotton stalks, branches, and bark, such as green and dry. Processed materials can be used in large-scale farms, biomass power plants, paper mills, etc.
- Place of Origin: china
- Brand Name: liuxing
- Model Number: 9ZP-30
【Technical Parameters】
Supporting power (kw/h) | Main power | Y180L-4(30) |
Feeding power | ZWD5.5-5A-17 | |
Machine quality (kg) | 2350 | |
Overall size (mm) | Use size | 4870X2990X4260 |
Transport size | 4870X2990X2510 | |
Spindle speed (r/min) | 500 |
【Performance】
Fresh corn stalk (t/h) | ≥30 |
Dry corn stalk (t/h) | ≥10 |
Dry straw (t/h) | ≥8 |
Dry straw (t/h) | ≥8 |
Cotton stalk (t / h) | ≥6 |
